Cisco Catalyst 9300L 24 Ports PoE Network Essentials 4x1G Uplink Switch
รหัสสินค้า : C9300L-24P-4G-E
ตรวจสอบสต็อกและระยะเวลาการสั่งซื้อสินค้าทุกครั้ง
- Downlinks total 10/100/1000 or PoE+ copper ports : 24 POE+
- Uplink configuration : 4x 1G fixed uplinks
- Software : Network Essentials
- Stacking bandwidth : 320 Gbps
- DRAM : 8 GB
- Flash : 16 GB
- Switching capacity : 56 Gbps
- Forwarding rate : 41.66 Mpps
- Mac Address : 32K
--- กรุณาตรวจสอบสินค้าก่อนสั่งซื้อทุกครั้ง ---
฿ 97,000.00 – ฿ 178,700.00
฿ 103,790.00 – ฿ 191,209.00 (ราคารวมภาษี)
Cisco Catalyst 9300L 24 Ports PoE Network Essentials 4x1G Uplink Switch
C9300L-24P-4G-E Overview
Cisco Catalyst 9300 Series is the next generation of the industry’s most widely deployed stackable switching platform. Built for security, IoT, and the cloud, these network switches form the foundation for Cisco’s Software-Defined Access, our leading enterprise architecture. Cisco Catalyst 9300L switches are the Catalyst 9300 switches with fixed modules.
Catalyst 9300L 24 Ports PoE 4x1G Uplink Quick Specs
Table 1 shows the Quick Specs.
Cisco Catalyst 9300L Switches Specification |
|
|
Designed to replace |
Catalyst 3850 |
|
Supported IOS |
Network Advantage, Network Essentials |
|
Network modules options |
Fixed Modules |
|
Stack Technology |
StackWise-320 |
|
Stacking bandwidth |
320 Gbps |
|
Total number of MAC addresses |
32,000 |
|
Total number of IPv4 routes (ARP plus learned routes) |
32,000 (24,000 direct routes and 8000 indirect routes) |
|
IPv4 routing entries |
– |
|
IPv6 routing entries |
16,000 |
|
Multicast routing scale |
8,000 |
|
QoS scale entries |
5,120 |
|
ACL scale entries |
5,120 |
|
Packet buffer per SKU |
16 MB buffer for 24 and 48 port Gigabit Ethernet models |
|
Flexible NetFlow (FNF) entries |
64,000 flow on 24- and 48-port Gigabit Ethernet models |
|
DRAM |
8 GB |
|
Flash |
16 GB |
|
VLAN IDs |
4094 |
|
Total Switched Virtual Interfaces (SVIs) |
1000 |
|
Jumbo frames |
9198 bytes |
|
Switching capacity |
56 Gbps – 176 Gbps |
|
Forwarding rate |
41.66 Mpps – 130.95 Mpps |
| Brand | ||||||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
||||||||||||||||||
| Product Type | ||||||||||||||||||
|
||||||||||||||||||
| Warranty | ||||||||||||||||||
|
||||||||||||||||||
| More | ||||||||||||||||||
|
||||||||||||||||||
Datasheet
Loading...
Reload document
Open in new tab Based on 0 reviews
Be the first to review “Cisco Catalyst 9300L 24 Ports PoE Network Essentials 4x1G Uplink Switch”
