Aten LCD17″ Rack Console LCD Panel with 16 Ports KVM

รหัสสินค้า : CL5716M
Availability:

ตรวจสอบสต็อกและระยะเวลาการสั่งซื้อสินค้าทุกครั้ง
สนใจ
เปรียบเทียบ
  • Integrated KVM console with 17-inch LED-backlit LCD monitor in a Slideaway housing
  • KVM Switch 16 Ports to control 16 Computer
  • Space saving technology – up to two consoles (one bus) control up to 8 computers
  • Dual Interface – supports computers and console with PS/2 or USB keyboards and mice
  • Multiplatform support – Windows, Linux, Mac, and Sun
  • Auto PS/2 and USB interface detection
  • Superior video quality – supports resolutions up to 1280 x 1024 @ 75 Hz
  • Port names automatically reconfigured when station sequence is changed
  • Two level password security – only authorized users can view and control computers
  • Supports one administrator and four user accounts with separate profiles
  • Auto Scan mode enables continuous monitoring of user-selected computers
  • Broadcast support – commands from the keyboard can be broadcast to all available computers on the installation
  • Hot pluggable – add or remove computers without having to power down the switch
  • Beeper on/off via hotkey and OSD
  • Free 16x 1.8M USB KVM Cables (USB/Video) for CS13xx, CL57XXM, KL3XXM
--- กรุณาตรวจสอบสินค้าก่อนสั่งซื้อทุกครั้ง ---

฿ 74,500.00
฿ 79,715.00 (ราคารวมภาษี)

ตรวจสอบสต็อกและระยะเวลาการสั่งซื้อสินค้าทุกครั้ง

Aten LCD 17-inch Rack Console LCD with 16 Ports KVM CL5716M

Aten LCD 17-inch Rack Console LCD with 16 Ports KVM | CL5716M

The CL5716M Slideaway LCD KVM Switch is a control unit that allows access to multiple computers from a single PS/2 or USB KVM (keyboard, video, and mouse) console. A single CL5716M can control up to 16 computers. As many as 31 additional KVM switches can be daisy-chained to the CL5716M, so that up to 256 computers can all be controlled from a single KVM console.

The CL5716M offers a space-saving, streamlined approach to KVM switch technology by integrating a keyboard, 17″ LCD monitor, and touchpad in a 1U rack-mountable sliding housing.

Package Contents

  • 1x CL5716 KVM Switch with standard Rack Mount Kit
  • 16x Custom KVM Cable (VGA, USB; 1.8m/6ft)
  • 1x Custom Console Cable (VGA, USB, PS/2; 27cm/0.88ft)
  • 1x Firmware Upgrade Cable
  • 1x Power Cord (6ft.)
  • 1x Grounding Wire (4ft.)
  • 1x User Manual
  • 1x Quick Start Guide

Specification

  • Exclusive LED illumination light – designed by ATEN to illuminate the keyboard and touchpad to allow visibility in low-light conditions
  • Integrated KVM console with 17″ LED-backlit LCD monitor in a Slideaway housing
  • Space saving technology – up to two consoles (one bus) control up to 8 computers
  • Daisy-chain up to 31 additional units – control up to 256 computers from a single console (With compatible KVM Switches: ACS1208A, ACS1216A, CS1708A,CS1716A)
  • Dual Interface – supports computers and console with PS/2 or USB keyboards and mice
  • Multiplatform support – Windows, Linux, Mac, and Sun
  • Auto PS/2 and USB interface detection
  • Superior video quality – supports resolutions up to 1280 x 1024 @ 75 Hz
  • Port names automatically reconfigured when station sequence is changed
  • Two level password security – only authorized users can view and control computers
  • Supports one administrator and four user accounts with separate profiles
  • Auto Scan mode enables continuous monitoring of user-selected computers
  • Broadcast support – commands from the keyboard can be broadcast to all available computers on the installation
  • Hot pluggable – add or remove computers without having to power down the switch
  • Beeper on/off via hotkey and OSD
