APC Easy UPS On-Line SRV Ext. Runtime 6000VA 230V with External Battery Pack

รหัสสินค้า : SRV6KIL
APC
Availability:

ตรวจสอบสต็อกและระยะเวลาการสั่งซื้อสินค้าทุกครั้ง
สนใจ
เปรียบเทียบ
  • Max Configurable Power (Watts) : 6000VA / 6000Watts
  • Other Output Voltages : 220, 240
  • Topology : Double conversion online
  • Waveform type : Sine wave
  • Interface Port(s) : DB-9 RS-232, Intelligent Smart Slot, USB
  • Control panel : Multi-function LCD status and control console
  • Output Connections : Terminal Block
  • Includes: Includes: (1) DC cable, Basic UPS signalling RS-232 cable, CD with software, USB cable, User manual
  • 2Years Warranty 8×5 On-Site

            SRV Model TOWER : แบบต่อแบตได้ // ไม่มี Powerchute (ไม่รวมค่าจัดส่งสินค้า)



--- กรุณาตรวจสอบสินค้าก่อนสั่งซื้อทุกครั้ง ---

฿ 97,000.00 ฿ 108,000.00
฿ 103,790.00 (ราคารวมภาษี)

ตรวจสอบสต็อกและระยะเวลาการสั่งซื้อสินค้าทุกครั้ง

APC Easy UPS On-Line SRV Ext. Runtime 6000VA 230V with External Battery Pack (SRV6KIL)

APC Easy UPS On-Line SRV Ext. Runtime 6000VA 230V with External Battery Pack (SRV6KIL)

Output

  • Max Configurable Power (Watts) : 6000VA / 6000Watts
  • Output Voltage Note : Configurable for 220 : 230 or 240 nominal output voltage
  • Efficiency at Full Load : 94.0 %
  • Output Frequency (sync to mains) : 50/60 Hz +/- 3 Hz Sync to mains
  • Other Output Voltages : 220, 240
  • Load Crest Factor : (3 : 1)
  • Topology : Double conversion online
  • Waveform type : Sine wave
  • Bypass : Internal bypass (automatic and manual)

Input

  • Input frequency : 40 – 70 Hz
  • Input voltage range for main operations : 110 – 300 Adjustable (half load), 176 – 300V
  • Efficiency at Full Load : 94.0 %
  • Other Input Voltages : 220, 240

Batteries & Runtime

  • Battery type : Lead-acid battery
  • Typical recharge time : 4hour(s)
  • Battery Charge Power (Watts) : 517 Watts
  • Extendable Run Time : 1
  • Runtime : View Runtime Graph

Communications & Management

  • Interface Port(s) : DB-9 RS-232, Intelligent Smart Slot, USB
  • Control panel : Multi-function LCD status and control console
  • Audible Alarm : Alarm when on battery : distinctive low battery alarm : overload continuous tone alarm
  • Emergency Power Off (EPO) : Yes

Surge Protection and Filtering

  • Surge energy rating : 600Joules

Physical

  • Maximum Height : 368MM, 36.8CM
  • Maximum Width : 380MM, 38.0CM
  • Maximum Depth : 485MM, 48.5CM
  • Net Weight : 73.0KG
  • Shipping weight : 79.0KG
  • Shipping Height : 460MM, 46.0CM
  • Shipping Width : 580MM, 58.0CM
  • Shipping Depth : 570MM, 57.0CM
  • Color : Black

Environmental

  • Operating Temperature : 0 – 40 °C
  • Operating Relative Humidity : 0 – 95 (Non-condensing) %
  • Operating Elevation : 0 – 3048meters
  • Storage Temperature : -15 – 60 °C
  • Storage Elevation : 0 – 15240meters
  • Audible noise at 1 meter from surface of unit : 55.0dBA
  • Protection Class : IP20

Conformance

  • Approvals : CE, IEC 62040-1-1, IEC 62040-1-2
  • Standard Warranty : 2Years Repair or Replace
SKU: SRV6KIL Categories: , , , Tags: , , , ,
Brand
Brand
Product Type
Product Type

UPS
More
UPS VA

6000 VA

UPS Watts

6000 Watts

UPS Application

Network and Server

UPS Topology

UPS Power Factor

1

UPS Full Load Backup Time

7 min

UPS Half Load Backup Time

18 min

UPS External Battery

รองรับการต่อ Battery เพิ่ม

UPS Max Battery Pack Support

4 Pack

UPS Network Card Support

Network Card Support

UPS Software

No Software

UPS Warranty

2Y Onsite 5×8
